The Ubiquiti RocketDish 5GHz 30dBi RD-5G30-LW is a high-gain directional parabolic antenna designed for long-range wireless networking and point-to-point connectivity. It operates across the 5.1–5.9GHz frequency range and provides 30dBi gain, making it suitable for establishing high-performance wireless backhaul links between buildings, towers, network sites, and remote locations.
The extended-depth reflector is designed to help reject unwanted noise and interference, particularly in co-location deployments. The antenna also features dual-linear polarization and narrow 5.8° horizontal and vertical beamwidths for focused wireless transmission.
| Product | Approximate Price |
|---|---|
| Ubiquiti RocketDish 5GHz 30dBi RD-5G30-LW | KSh 24,000 – 30,000 |
| Specification | Details |
|---|---|
| Model | RD-5G30-LW |
| Antenna Type | Directional Parabolic Dish |
| Frequency Range | 5.1–5.9GHz |
| Gain | 30dBi |
| HPOL Beamwidth | 5.8° |
| VPOL Beamwidth | 5.8° |
| Polarization | Dual-Linear |
| Front-to-Back Ratio | 30dB |
| Cross-Polarization Isolation | 35dB minimum |
| Maximum VSWR | 1.6:1 |
| Dimensions | 650 × 650 × 386mm |
| Weight | 7.4kg |
| Wind Survivability | 200km/h |
| Wind Loading | 790N @ 200km/h |
| Mounting | Universal Pole Mount |
| Rocket Integration | Rocket Bracket Included |
The specifications are based on Ubiquiti's current technical specifications and product documentation.
The RD-5G30-LW is designed to integrate with Ubiquiti Rocket radios, with Ubiquiti describing the RocketDish and Rocket combination as a solution for high-performance wireless links.
The antenna is specified for wind survivability of up to 200km/h and includes the universal pole mount and Rocket bracket required for installation.
| Pros | Cons |
|---|---|
| 30dBi high gain | Requires careful alignment |
| Narrow 5.8° beamwidth | Directional rather than wide coverage |
| Extended-depth reflector | 7.4kg installation weight |
| Dual-linear polarization | Designed primarily for compatible Rocket radio deployments |
| 200km/h wind survivability | 5GHz signals can be affected by obstacles |
| Integrated Rocket bracket | Requires suitable mounting location |
| Weatherproof RF connectors | Not intended as an indoor antenna |
| Excellent for long-range links | — |
The RD-5G30-LW is a 5GHz, 30dBi directional parabolic antenna designed for long-range wireless point-to-point and backhaul applications.
The antenna operates across the 5.1–5.9GHz frequency range.
The Ubiquiti RD-5G30-LW provides 30dBi antenna gain.
It has a 5.8° horizontal beamwidth and a 5.8° vertical beamwidth at 3dB.
Yes. Its high gain and narrow directional beam make it suitable for long-range point-to-point wireless links and network backhaul deployments.
Yes. It uses dual-linear polarization for wireless networking applications.
Yes. It is designed for outdoor deployment and has a specified wind survivability of up to 200km/h.
Yes. Ubiquiti specifies that the universal pole mount and Rocket bracket are included.
The RocketDish is designed to integrate with Ubiquiti Rocket radios, making it suitable for Rocket-based wireless backhaul and bridging deployments.
The Ubiquiti RocketDish 5GHz 30dBi RD-5G30-LW is a high-performance directional antenna designed for long-range wireless networking, point-to-point links, and professional wireless backhaul. With 30dBi gain, a 5.1–5.9GHz frequency range, dual-linear polarization, narrow 5.8° beamwidth, and an extended-depth reflector, it provides focused connectivity while helping reduce interference in demanding outdoor deployments.
