Supports Point-to-Point and Point-to-Multipoint deployments
Designed for efficient outdoor broadband connectivity
Warranty: The warranty tendered hereunder, on the electronic product(s) sold under this invoice will be provided exclusively by their respective Authorized Agents/Distributors and are limited to the period indicated from the date ofyour invoice, except otherwise mentioned as per the warranty conditions as carried along with the products(s)
The Ubiquiti NanoStation Loco M5 (LOCOM5) is a compact and cost-effective 5GHz wireless CPE designed for outdoor broadband connectivity. It combines an integrated 13dBi antenna with 2×2 MIMO and airMAX technology to provide reliable wireless links for homes, businesses, and network installations.
Its compact design makes the LOCOM5 easy to deploy where space is limited, while its outdoor-rated enclosure helps it withstand demanding environmental conditions. It can be used for wireless bridging, client connectivity, and Point-to-Point or Point-to-Multipoint network deployments.
Ubiquiti NanoStation Loco M5 (LOCOM5) Price in Kenya
Product
Price in Kenya
Ubiquiti NanoStation Loco M5 (LOCOM5)
KSh 9,000 – 11,000
Ubiquiti NanoStation Loco M5 (LOCOM5) Key Specs
Specification
Details
Frequency
5 GHz
Operating Frequency
5170–5875 MHz
Antenna Gain
13 dBi
Polarization
Dual Linear
Beamwidth
45° H / 45° V / 45° Elevation
MIMO
2×2
Ethernet
1 × 10/100 MbE RJ45
Power Method
Passive PoE
PoE Adapter
24V 0.5A included
Maximum Power Consumption
5.5W
Dimensions
161 × 31 × 80 mm
Weight
180g
Operating Temperature
-30°C to 75°C
Enclosure
Outdoor UV-stabilized polycarbonate
Ubiquiti NanoStation Loco M5 (LOCOM5) Performance
5GHz Wireless Connectivity: Provides a cleaner wireless environment compared with many congested 2.4GHz deployments.
2×2 MIMO: Uses dual-polarized wireless technology to improve link performance and reliability.
airMAX Technology: Supports efficient wireless communication for outdoor network deployments.
150+ Mbps Throughput: Commonly specified for up to 150+ Mbps outdoor throughput depending on network conditions and configuration.
Adjustable Channels: Supports multiple channel widths for flexible wireless planning.
Ubiquiti NanoStation Loco M5 (LOCOM5) Smart Features
airMAX TDMA technology
Access Point and Station operation
Point-to-Point wireless bridging
Point-to-Multipoint connectivity
Wireless client connectivity
Flexible channel-width configuration
Web-based network management
Integrated antenna and radio design
Ubiquiti NanoStation Loco M5 (LOCOM5) Design & Build
Compact dimensions of 161 × 31 × 80 mm
Lightweight 180g construction
Outdoor UV-stabilized polycarbonate enclosure
Included pole-mount installation system
Designed for permanent outdoor deployment
Operates from -30°C to 75°C
Low maximum power consumption of 5.5W
Ubiquiti NanoStation Loco M5 (LOCOM5) Connectivity
1 × 10/100 MbE RJ45 Ethernet port
Passive PoE power input
24V 0.5A PoE adapter included
5GHz wireless connectivity
Dual-linear polarized integrated antenna
13dBi antenna gain
Ubiquiti NanoStation Loco M5 (LOCOM5) Use Cases
Wireless Bridges: Connect two buildings or network locations wirelessly.
Internet Distribution: Provide outdoor broadband connectivity to remote users.
Point-to-Point Links: Establish dedicated wireless connections between two locations.
Point-to-Multipoint Networks: Work as part of an outdoor wireless distribution system.
ISP Deployments: Suitable for cost-effective customer-premises installations.
Rural Connectivity: Useful for extending network access where wired infrastructure is difficult to install.
Business Networks: Connect separate offices, buildings, warehouses, or other facilities.
Ubiquiti NanoStation Loco M5 (LOCOM5) Pros & Cons
Pros
Cons
Compact and lightweight
Uses 10/100 Ethernet
13dBi integrated antenna
5GHz coverage requires suitable line of sight
2×2 MIMO
Designed primarily for outdoor wireless links
Low 5.5W power consumption
Not intended for high-density Wi-Fi access
Passive PoE included
Requires careful channel planning
Outdoor UV-stabilized construction
Performance varies with environmental conditions
Ubiquiti NanoStation Loco M5 (LOCOM5) FAQs
What is Ubiquiti NanoStation Loco M5 (LOCOM5)?
The Ubiquiti NanoStation Loco M5 (LOCOM5) is a compact 5GHz airMAX wireless CPE designed for outdoor broadband, wireless bridging, and Point-to-Point or Point-to-Multipoint connectivity.
What is the antenna gain of the Ubiquiti NanoStation Loco M5 (LOCOM5)?
It features an integrated 13dBi dual-linear polarized antenna.
Does Ubiquiti NanoStation Loco M5 (LOCOM5) support 2×2 MIMO?
Yes. The LOCOM5 uses 2×2 MIMO technology for improved wireless communication.
What Ethernet port does Ubiquiti NanoStation Loco M5 (LOCOM5) have?
It has one 10/100 MbE RJ45 Ethernet port.
Does Ubiquiti NanoStation Loco M5 (LOCOM5) include a PoE adapter?
Yes. The current specification lists a 24V 0.5A Passive PoE adapter as included.
Is Ubiquiti NanoStation Loco M5 (LOCOM5) suitable for outdoor use?
Yes. It features an outdoor UV-stabilized enclosure and is designed to operate in temperatures from -30°C to 75°C.
Ubiquiti NanoStation Loco M5 (LOCOM5) Conclusion
The Ubiquiti NanoStation Loco M5 (LOCOM5) is a practical solution for affordable 5GHz outdoor wireless networking. With its 13dBi integrated antenna, 2×2 MIMO, airMAX technology, compact construction, and low power consumption, it is well suited for wireless bridges, broadband CPE installations, and Point-to-Point or Point-to-Multipoint networks. Its simple installation and outdoor-ready design make it a dependable choice for extending network connectivity over wireless links in Kenya.
