Stock Status:
Condition: New
SKU : 8596M74
The D-Link DMC-810SSC Media Converter is designed to convert Gigabit Ethernet signals from copper twisted-pair cabling into 1000BASE-LX Gigabit single-mode fiber connectivity. It provides an effective way to extend network connections beyond the limitations of standard copper Ethernet cabling.
The DMC-810SSC supports single-mode fiber transmission over distances of up to 10 km using a 1310 nm wavelength. With a Gigabit RJ-45 interface, SC fiber connection, Auto-MDI/MDIX, plug-and-play operation, and full wire-speed forwarding, it is suitable for enterprise networks, campuses, offices, and long-distance fiber infrastructure.
| Product | Price |
|---|---|
| D-Link DMC-810SSC Media Converter | KSh 7,500 |
| Specification | Details |
|---|---|
| Model | DMC-810SSC |
| Device Type | Gigabit Media Converter |
| Copper Port | 1 x 10/100/1000BASE-T RJ-45 |
| Fiber Port | 1 x 1000BASE-SX/LX SC |
| Fiber Type | Single-mode |
| Fiber Standard | 1000BASE-LX |
| Maximum Fiber Distance | Up to 10 km |
| Wavelength | 1310 nm |
| Copper Distance | Up to 100 m |
| Data Rate | 10/100/1000 Mbps |
| Duplex Mode | Full Duplex |
| Standards | IEEE 802.3ab and IEEE 802.3z |
| Auto-MDI/MDIX | Yes |
| Transmission Mode | Store-and-forward |
| Forwarding Rate | Full wire-speed |
| Power Input | 5V/1A external adapter |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -20°C to 70°C |
| Humidity | 5% to 90% RH non-condensing |
| Dimensions | 95 × 70 × 26 mm |
| LED Indicators | Power and LINK/ACT |
| Installation | Standalone or Chassis |
| Pros | Cons |
|---|---|
| Supports Gigabit Ethernet | Requires single-mode fiber |
| Up to 10 km fiber distance | Uses SC fiber connectivity |
| 1310 nm wavelength | Requires compatible fiber equipment |
| Full wire-speed forwarding | External power adapter required |
| Auto-MDI/MDIX | — |
| Standalone or chassis installation | — |
| Compact design | — |
What is the D-Link DMC-810SSC used for?
The DMC-810SSC is used to convert Gigabit Ethernet signals from copper RJ-45 connections to 1000BASE-LX single-mode fiber.
What is the maximum fiber distance supported?
The DMC-810SSC supports single-mode fiber connections of up to 10 km.
What type of fiber does the DMC-810SSC use?
It uses single-mode fiber with a 1000BASE-LX SC fiber interface.
What wavelength does the DMC-810SSC use?
The converter operates at a 1310 nm wavelength.
What Ethernet speeds does the DMC-810SSC support?
Its copper interface supports 10 Mbps, 100 Mbps, and 1000 Mbps Ethernet.
Does the DMC-810SSC support Auto-MDI/MDIX?
Yes. Auto-MDI/MDIX automatically detects the appropriate copper Ethernet connection configuration.
Can the DMC-810SSC be installed in a chassis?
Yes. It can operate as a standalone media converter or be installed in a compatible D-Link chassis.
The D-Link DMC-810SSC Media Converter is a reliable solution for extending Gigabit Ethernet networks over single-mode fiber. With 10/100/1000BASE-T support, 1000BASE-LX connectivity, a 1310 nm wavelength, up to 10 km fiber reach, SC connectivity, Auto-MDI/MDIX, and full wire-speed forwarding, it is suitable for enterprise networks, campuses, CCTV systems, and long-distance network infrastructure. At KSh 7,500, it offers a practical solution for connecting copper Gigabit Ethernet equipment to single-mode fiber networks.
