Description

Ubiquiti UniFi U7 Pro Outdoor Access Point Wi-Fi 7 6 Spatial Streams U7-Pro-Outdoor Overview

The Ubiquiti UniFi U7 Pro Outdoor Access Point U7-Pro-Outdoor is a high-performance outdoor WiFi 7 access point designed for campuses, hotels, commercial properties, warehouses, residential estates, event venues, and other demanding outdoor environments. It combines tri-band 2.4GHz, 5GHz and 6GHz connectivity with six spatial streams and a high-speed 2.5 GbE uplink. Its integrated directional antenna can provide coverage of up to 465 m² in open spaces, while included external omni antennas provide a more balanced coverage pattern when required. The U7-Pro-Outdoor supports more than 300 clients and uses PoE+ for convenient installation. Its rugged outdoor construction provides IPX6 protection, with IP67 protection available using the cable-gland door kit.

Ubiquiti UniFi U7 Pro Outdoor Access Point Wi-Fi 7 6 Spatial Streams U7-Pro-Outdoor Price in Kenya

Ubiquiti UniFi U7 Pro Outdoor Access Point Wi-Fi 7 6 Spatial Streams U7-Pro-Outdoor Key Specs

The official specifications confirm six spatial streams, 465 m² directional coverage, 300+ clients, 2.5 GbE connectivity, PoE+ power, IPX6/IP67 weather protection, and wall or pole mounting.

Ubiquiti UniFi U7 Pro Outdoor Access Point Wi-Fi 7 6 Spatial Streams U7-Pro-Outdoor Performance

• WiFi 7 delivers improved wireless efficiency and throughput.
• 6GHz connectivity provides up to 5.8 Gbps maximum data rate.
• 5GHz connectivity provides up to 4.3 Gbps maximum data rate.
• 2.4GHz connectivity supports up to 688 Mbps.
• Six spatial streams improve multi-client wireless performance.
• 2×2 MU-MIMO enables efficient communication with multiple wireless devices.
• Up to 320 MHz channel bandwidth is supported on 6GHz.
• The integrated directional antenna can provide up to 465 m² open-space coverage.
• External omni antennas can provide up to 160 m² of more balanced coverage.
• The 2.5 GbE uplink helps reduce wired network bottlenecks.
• Supports more than 300 connected clients.
• Suitable for demanding outdoor wireless deployments.

Ubiquiti UniFi U7 Pro Outdoor Access Point Wi-Fi 7 6 Spatial Streams U7-Pro-Outdoor Smart Features

• Wireless meshing for flexible UniFi network expansion.
• 802.11r fast roaming for smoother movement between access points.
• 802.11k radio resource management.
• 802.11v BSS transition management.
• Band steering for improved client distribution.
• Advanced radio management.
• Passpoint or Hotspot 2.0 support.
• Captive hotspot portal support.
• Guest network isolation.
• Private Pre-Shared Key support.
• WiFi speed limiting for bandwidth management.
• Client device isolation.
• WiFi scheduling.
• Dynamic RADIUS-assigned VLAN.
• RADIUS over TLS support.
• Software-switchable antenna configuration.

Ubiquiti UniFi U7 Pro Outdoor Access Point Wi-Fi 7 6 Spatial Streams U7-Pro-Outdoor Design & Build

• Rugged outdoor design built for exposed wireless deployments.
• UV-stabilized polycarbonate and aluminum alloy construction.
• IPX6 weatherproofing for outdoor environments.
• IP67 protection is available with the cable-gland door kit.
• Integrated directional antenna for extended-range deployments.
• Included external omni antennas provide an alternative coverage pattern.
• Wall and pole mounting support.
• Supports pole diameters from approximately 25 to 63.5 mm.
• Compact 170 × 208 × 66.5 mm device dimensions without the mount.
• Device weight is approximately 1.2 kg.
• Operating temperature range of -30°C to 60°C.
• Designed for outdoor campuses, commercial properties and large compounds.

Ubiquiti UniFi U7 Pro Outdoor Access Point Wi-Fi 7 6 Spatial Streams U7-Pro-Outdoor Connectivity

• Tri-band 2.4GHz, 5GHz and 6GHz WiFi connectivity.
• WiFi 7 IEEE 802.11be support.
• One 2.5 GbE RJ45 network interface.
• PoE+ provides both power and network connectivity.
• Backward compatibility with previous WiFi generations.
• Supports wireless mesh networking.
• Supports VLAN-based network segmentation.
• Supports WPA2 and WPA3 security.
• Supports advanced RADIUS authentication.
• Integrates with the wider UniFi networking ecosystem.
• 6GHz connectivity provides additional spectrum for compatible devices.
• Software-switchable directional and omni antenna operation.

Ubiquiti UniFi U7 Pro Outdoor Access Point Wi-Fi 7 6 Spatial Streams U7-Pro-Outdoor Use Cases

• Large outdoor residential compounds.
• Hotels and hospitality properties.
• Schools and university campuses.
• Business campuses and office compounds.
• Shopping centers and commercial properties.
• Warehouses and industrial premises.
• Outdoor event venues.
• Parks and recreational facilities.
• Restaurants with outdoor spaces.
• Stadiums and public venues.
• Large estates requiring extended wireless coverage.
• High-density outdoor networks with many connected devices.

Ubiquiti UniFi U7 Pro Outdoor Access Point Wi-Fi 7 6 Spatial Streams U7-Pro-Outdoor Pros & Cons

Ubiquiti UniFi U7 Pro Outdoor Access Point Wi-Fi 7 6 Spatial Streams U7-Pro-Outdoor FAQs

What is the Ubiquiti UniFi U7 Pro Outdoor Access Point U7-Pro-Outdoor?

The U7-Pro-Outdoor is a high-performance outdoor WiFi 7 access point designed for long-range and high-capacity wireless deployments.

Does the U7-Pro-Outdoor support WiFi 7?

Yes. The U7-Pro-Outdoor supports WiFi 7 based on the IEEE 802.11be standard.

What WiFi bands does the U7-Pro-Outdoor support?

It supports 2.4GHz, 5GHz and 6GHz wireless bands.

How many spatial streams does the U7-Pro-Outdoor have?

The U7-Pro-Outdoor features six spatial streams with 2×2 MU-MIMO across its 2.4GHz, 5GHz and 6GHz radios.

What is the maximum speed of the U7-Pro-Outdoor?

The maximum data rates are up to 5.8 Gbps on 6GHz, 4.3 Gbps on 5GHz, and 688 Mbps on 2.4GHz.

How much area can the U7-Pro-Outdoor cover?

The integrated directional antenna can cover up to approximately 465 m² or 5,000 ft² in open space. With the external omni antennas, coverage is listed at up to approximately 160 m² or 1,750 ft².

How many devices can the U7-Pro-Outdoor support?

The U7-Pro-Outdoor is designed to support more than 300 connected clients.

Does the U7-Pro-Outdoor have a 2.5 GbE port?

Yes. It features one 2.5 GbE RJ45 uplink for high-speed wired networking.

Does the U7-Pro-Outdoor support PoE+?

Yes. The access point is powered through PoE+ and has a maximum power consumption of 21W.

Is the U7-Pro-Outdoor weatherproof?

Yes. It has IPX6 weatherproofing, with IP67 protection when used with the cable-gland door kit.

Can the U7-Pro-Outdoor be mounted on a pole?

Yes. The U7-Pro-Outdoor supports both wall and pole mounting, with mounting hardware included.

Can the U7-Pro-Outdoor be managed centrally?

Yes. It integrates with UniFi Network for centralized configuration, monitoring, security, firmware management and wireless administration.

Ubiquiti UniFi U7 Pro Outdoor Access Point Wi-Fi 7 6 Spatial Streams U7-Pro-Outdoor Conclusion

The Ubiquiti UniFi U7 Pro Outdoor Access Point U7-Pro-Outdoor is a powerful solution for demanding outdoor wireless networks. With tri-band WiFi 7, six spatial streams, 6GHz connectivity, up to 5.8 Gbps on 6GHz, 465 m² open-space directional coverage, support for more than 300 clients, a 2.5 GbE uplink, PoE+ power, and rugged IPX6/IP67 protection, it is well suited for campuses, hotels, commercial properties, warehouses, estates, event venues, and other large outdoor environments. Its integrated directional antenna and switchable external omni antennas provide additional deployment flexibility, while centralized UniFi Network management makes it easier to configure and operate as part of a larger UniFi network.
