The Ubiquiti PowerBeam M5 400 PBE-M5-400 is a 5 GHz outdoor wireless bridge designed for high-performance point-to-point connectivity. It combines a 400 mm directional dish with 25 dBi antenna gain to provide focused wireless transmission over long distances. Ubiquiti rates the device for 150+ Mbps throughput.
The PowerBeam M5 400 is suitable for connecting buildings, offices, campuses, CCTV locations and remote network sites where running physical cabling is difficult or expensive. Its directional design helps concentrate the wireless signal toward the receiving endpoint for dependable long-range communication.
| Product | Approximate Price |
|---|---|
| Ubiquiti PowerBeam M5 400 PBE-M5-400 | KSh 18,000 – 25,000 |
| Specification | Details |
|---|---|
| Model | PBE-M5-400 |
| Wireless Technology | airMAX |
| Frequency | 5 GHz |
| Frequency Range | 5170–5875 MHz worldwide |
| Antenna Gain | 25 dBi |
| Throughput | 150+ Mbps |
| Antenna Size | 400 mm |
| Polarization | Dual Linear |
| Network Interface | 1 × 10/100/1000 Ethernet |
| Maximum TX Power | 26 dBm |
| Power Method | Passive PoE |
| Power Supply | 24V 0.5A Gigabit PoE |
| Maximum Power Consumption | 8W |
| Dimensions | 420 × 420 × 275 mm |
| Weight | Approximately 1.8 kg |
| Mounting | Pole Mount |
| Operating Temperature | -40°C to 70°C |
| Wind Survivability | Up to 200 km/h |
These specifications are based on Ubiquiti's current technical specifications and product documentation.
The PowerBeam M5 400 uses a compact directional dish design with a UV-stabilized outdoor enclosure. It measures approximately 420 × 420 × 275 mm and weighs about 1.8 kg. The included pole mounting system makes it suitable for outdoor installations.
Its enclosure and mounting system are designed for challenging outdoor environments. Ubiquiti specifies wind survivability up to 200 km/h and an operating temperature range from -40°C to 70°C.
| Pros | Cons |
|---|---|
| 25 dBi directional antenna | Requires accurate alignment |
| 150+ Mbps throughput | Uses older 5 GHz Wi-Fi technology |
| Gigabit Ethernet interface | Passive PoE requires correct power equipment |
| Long-distance wireless capability | Directional design is not suitable for general Wi-Fi coverage |
| Durable outdoor construction | Requires clear line of sight for best results |
| Low 8W power consumption | 5 GHz performance can be affected by obstacles |
It is primarily used for long-distance 5 GHz wireless point-to-point connections such as building-to-building networking and network backhaul.
The PBE-M5-400 features a 25 dBi antenna gain.
Ubiquiti lists the PowerBeam M5 400 with 150+ Mbps throughput.
Yes. It features one 10/100/1000 Mbps Gigabit Ethernet port.
It uses passive PoE and includes a 24V 0.5A Gigabit PoE adapter.
Yes. It has an outdoor UV-stabilized enclosure and is designed to withstand harsh environmental conditions, including wind speeds up to 200 km/h.
The device operates in the 5 GHz range, with Ubiquiti specifying 5170–5875 MHz for worldwide operation.
The Ubiquiti PowerBeam M5 400 PBE-M5-400 is a reliable outdoor 5 GHz wireless bridge for long-distance network connections. Its 25 dBi directional antenna, 150+ Mbps rated throughput, Gigabit Ethernet port and durable outdoor construction make it a practical choice for point-to-point links, network backhaul, CCTV connectivity and building-to-building communication.
